- Open House - September 7, 2017
Raise will have 3 models on display consisting of:
- A table top reservoir model depicting flow in a horizontal wellbore, showing 7 segmented flow fractures with different work flows depicting how wells deplete at the heel section and how drawdown along the entire Hz section affects better ultimate recovery.
- A table top model of conventional rod pump technology at various landed deviations and how Raise's High Angle Lift Solution (HALS) performs in wellbores from 45 degrees to 90 degrees.
- A 40ft length x 114mm (4 1/2”) horizontal wellbore model with a build section that can be placed from 90 degrees to 65 degrees deviation. This model depicts toe flow and also has an inlet at the heel section showing gas interference. The model is a good visual of how cross sectional areas of the wellbore react to gas and fluid inflow and how slugging can occur and be mitigated. The model is representative of two phase flow with a fluid rate of 160 bbls/day and 800 scf gas/bbl.
